LTB lab balance

Luna LTB/LBB Top Loading Precision Balances

Luna top loading precision balances deliver a combination of durability, performance and elegance. The stylish LCD shows results in 24mm white digits on a contrasting black background for enhanced visibility. The large stainless steel weighing pan is easy to load and keep clean. Collect and transmit information quickly to printers and computers via USB or RS-232.

Key Specifications

Capacity options
2600g - 15000g
Readability options
0.01g - 0.1g
Pan Size
185x185mm
scales and balances warranty

Features and Benefits

  • Vivid, backlit LCD easily visible in any lighting conditions
  • Colour-coded keys facilitate quick recognition of the most frequently used buttons
  • Level indicator and adjustable feet ensure proper balance setup for optimum weighing results
  • Large, grade 304 stainless steel pan allows easy cleaning
  • Sealed keypad protects against dirt and spills
  • USB and RS-232 interfaces provide speedy communication with computers and printers
  • AC adapter included
  • Multilingual display allows use in many different countries
  • Parts counting with preset sample sizes
  • Printouts include date and time for data tracking within Good Laboratory Practices (GLP) guidelines
  • Selectable digital filtering for animal/dynamic weighing enables consistent results for moving subjects
  • Auto power-off to save energy
  • Security slot for optional lock and cable to help prevent theft
  • A 5-year warranty means quality assured for years of use.

Technical Specification & Model Options

Model Options

 LTB 2602i 2600g capacity, 0.01g readability, automatic internal calibration
LTB 3602i 3600g capacity, 0.01g readability, automatic internal calibration
LTB 4602i 4600g capacity, 0.01g readability, automatic internal calibration
LTB 6002i 6000g capacity, 0.01g readability, automatic internal calibration
LTB 2602e 2600g capacity, 0.01g readability, manual external calibration
LTB 3602e 3600g capacity, 0.01g readability, manual external calibration
LTB 4602e 4600g capacity, 0.01g readability, manual external calibration
LTB 6002e 6000g capacity, 0.01g readability, manual external calibration
LBB 6001e 6000g capacity, 0.1g readability, manual external calibration
LBB 8001e 8000g capacity, 0.1g readability, manual external calibration
LBB 12001e 12000g capacity, 0.1g readability, manual external calibration
LBB 15001e 15000g capacity, 0.1g readability, manual external calibration

General Specifications

 Pan Size 185x185mm
Weighing Units ct, custom unit, dr, dwt, g, GN, mg, mm, N, oz, ozt, T, tl.H, tl.S, tl.T
Interface RS-232/USB
Display Backlit LCD with 24mm high digits

Power

 Power Supply 18VDC 830mA adapter

Operating Conditions

 Operating Temperature 15° to 35°C / 59° to 95°F

Product Information

   Construction   Net Weight ABS plastic   4.5 – 5.9kg

Dimensions

 Draft Shield Type Overall Dimensions N/A 224x374x95mm
